High flexible system, right for any application specially in extreme situation.

Coupler:Giunto-girevole

  • Steel grade S355JR, following UNI EN 10113-1/2/3;
  • Cold formed;
  • 4,75 mm thickness.

Corrosion protection:

  • Tropicalization: passive electrolytic galvanization;
  • Min. coating thickness 10 ηm.

Features:

  • Licensed for uniform building loads of 300 daN/ m2;
  • Total flexibility;
  • ­Connectable with the prefabricated system;
  • Width max: 1200 mm;
  • Span max: 1800 mm.

Manufacturing Standards:Giunto-forgiati

  • Autorizzazione ministeriale: n° 23813/PR-7-A-51 del 28/12/1982;
  • Successive estensioni: n° 21493/OM-4 del 16/09/1999;
  • UNI EN 74;
  • D.P.R. 07/01/1956 n° 164.
